High-Precision Backgauge
Dual linear guides keep positioning repeatability within +/-0.02 mm.
Laser Cutting Machine
High-efficiency handheld fiber laser welding solution for precise, clean seams.
- Clean, precise welds with low heat input for minimal deformation.
- High efficiency — up to 4× faster than traditional TIG.
- Ergonomic handheld torch for comfortable long sessions.
- Supports stainless steel, carbon steel, and aluminum alloys.
Specifications
Laser Power
1000W / 1500W / 2000W
Welding Modes
Continuous / Pulse
Wire Feeding
Optional automatic wire feeder
Cooling
Integrated water chiller
Weld Thickness
0.5 - 6 mm
Input Voltage
AC 220-380V, 50/60Hz
Standard Configuration
Safety Valve Block
Bosch Rexroth hydraulic valve block with redundant monitoring.
Hose Connector Set
German EMB hoses and fittings secure the hydraulic loop.
Electrical Cabinet
Schneider contactors, relays, and clearly labeled wiring harness.
Optional CNC Control Packages
CTP2007 Touch CNC
Servo package with multi-axis automation
- Automatic calculation of bending depth and crowning
- 20-step program memory with dwell control
- Automatic calculation of bending depth and crowning
- ndependent control of slider, backgauge, and stop fingers
E210 Compact CNC
Efficient controller for daily production
- 100 programs, each supporting up to 25 bends
- 100 programs, each supporting up to 25 bends
- Modular I/O for clamp, crowning, and backgauge options
- Y-axis and X-axis positioning accuracy up to 0.01 mm
Key Technical Parameters
| Model | Nominal Force | Worktable Length | Throat Depth | Slider Stroke | Max Opening Height | Main Motor Power | Machine Weight | Overall Dimension (LxWxH) |
|---|---|---|---|---|---|---|---|---|
| 63T/2500 | 630 kN | 2500 mm | 250 mm | 200 mm | 420 mm | 5.5 kW | 4200 kg | 3200 x 1300 x 2200 mm |
